Jelly Candy Depositing Production Line

Jelly Candy Depositing Production Line

LJC series continuous vacuum film depositing production line is mainly used for Jelly Candy pouring production. The LJC series continuous vacuum film pouring line is capable of producing not only transparent crystal sugar, double-colored sugar, double-flavored sugar, sandwich candy, but also spiral spray candy and many other colors and flavors.

Features of Jelly Candy Depositing Production Line

  1. Precise steam temperature control system and quantitative pouring, the minimum pouring amount can reach 1g

  2. Three different output corresponding to different customer needs

  3. Food grade 304 stainless steel material ensures the hygiene and food safety of the production process

  4. High-speed pouring, rapid cooling and efficient demoulding system provide customers with perfect products

  5. Mature processing technology, convenient replacement of spare parts, perfect after-sales service system

  6. Production lines can be customized to fit your operation perfectly.

  7. Simply replace the molds and other components of the line to produce various shapes of jelly candy or gummy.

  8. Syrup flow rate is precisely controlled by frequency control system to ensure stability.

Product standardization machine

Model JLM-1200
Capacity 700kg/h
Power consumption 7kw
Water consumption 1800L/h
Steam consumption 600kg/h
Steam pressure0.7Mpa
Compressed air pressure0.6Mpa
Size(L*W*H)2000*1200*2450mm

Jelly Candy Depositing Production Line Specification

Model LJC-II LJC-III LJC-IV
Capacity(5g candy) 360kg/h 500kg/h 720kg/h
Power consumption(cooker) 16kw 23kw 23kw
Power consumption(depositor) 17kw 19kw 23kw
Compressed air consumption 0.5m3/min
0.5m3/min
0.5m3/min
Compressed air pressure 0.4-0.6Mpa 0.4-0.6Mpa 0.4-0.6Mpa
Size(L*W*H) 135000*2000*2700mm 135000*2500*2700mm 135000*2800*2700mm
Weight 6000kgs 7500kgs 8000kgs
